General information
Product name
ASUS TUF GAMING B850M-PLUS WIFI.Brand
ASUS
ASUSModel
90MB1IY0-M0EAY0Processor
Processor support
AMD AM5Number of CPUs supported
1Chipset
Chipset
AMD B850Memory
Memory format
4 X DIMM 288 pins (DDR5)Memory Frequency(ies)
DDR5 6400 MHzDDR5 6200 MHzDDR5 6600 MHzDDR5 6800 MHzDDR5 7000 MHzDDR5 7200 MHzDDR5 7600 MHzDDR5 7800 MHzDDR5 7900 MHzDDR5 8000 MHzDDR5 6000 MHzDDR5 5800 MHzDDR5 5600 MHzDDR5 5400 MHzDDR5 5200 MHzDDR5 5000 MHzDDR5 4800 MHzMemory type
DDR5Memory technology
Dual ChannelMaximum RAM capacity per slot
48 GBMaximum RAM capacity
192 GBGraphic
Integrated graphics controller
NoCompatible graphics core integrated in the CPU
YesExpansion slots
Graphic connector(s)
1 X PCI Express 5.0 x16Number and Type of slots
1 X PCI Express 4.0 x1Multi-GPU type
NoneAudio
Audio Chipset
Realtek ALC1220PNumber of audio channels
8Network
Number of ports/Ethernet controler
1 X Integrated Realtek 2.5 GbENetwork standard(s)
Wi-Fi 6EBluetooth 5.32.5 Gbps Gigabit Ethernet (2.5 GbE)Wi-Fi
YesStorage
RAID supported
YesHard drives connectors
2 X M.2 – PCI-E 4.0 x44 X Serial ATA 6Gb/s (SATA Revision 3)1 X M.2 – PCI-E 5.0 x4Number of M.2 slot(s)
3Supported RAID Modes
51010Connectivity
Motherboard connector location
Standard connectors (on the motherboard)Rear panel connectors
1 X DisplayPort Female4 X USB 2.0BIOS Flash Update1 X HDMI Female1 X USB 3.2 Type C3 X USB 3.11 X RJ45 Female4 X USB 3.05 X 3.5mm Jack Female Stereo2 X SMAAdditional connectors
1 X Internal USB 3.1 Type CChassis intrusion1 X Serial (RS-232)2 X Internal USB 3.03 X Internal USB 2.01 X ATX 24 Pin2 X +12V (Power supply P8)Front panel audio3 X Addressable LED RGB connector(s)Physical characteristics
Motherboard format
Micro ATXLength
244 mmWidth
244 mmEquipment
Advanced overclocking features
YesUse
GamerLED
NoWarranties
Commercial warranty
Seller 3 years
